I had a bit of luck recently and got a 35W HID canister light from a friend for a good price. His was broken and he had already bought a new one, so I had a go at it. The lamp and driver curcuit seemed to be working, but the battery pack was dead. Anyway, building a battery pack should be a doable build, so I bought it from him.

Canister lights are high powered lights often used by divers, a very popular choice is to use 21W HID bulbs (HID - High Intensity Discharge - the same type of bulbs used in modern cars as head lamps). The one I got is a quite powerful 35W version (some people even use 50W versions - butmostly for video lights).

The original battery pack was basically 6 rectangular Li-Po 10 Ah cells, connected in 2 series with 3 cells each (and balance charger circuits + undervoltage/overvoltage protection). They were similar to these from batteryspace.com (which also sells exactly the same protection circuit). The original pack gave the light about 5.5 hours runtime, I thought about making a similar pack - but I rarely need that much runtime. Most of the dives I do are only 45-60 minutes long. Instead of going the dangerous Li-Po road (check out youtube, these things explode and burn if handled incorrectly)

.. and the batteries in the videos are usually much smaller than the large 20 Ah pack the canister originally had. I decided to go with the much safer NIMH (nickel–metal hydride) cell route. NIMH are much less energy dense per unit of weight, but much easier to handle and doesn't need elaborate protection circuits. Having a heavy canister is actually good for diving, it just replaces weights I would have to bring in my belt anyway. I looked around for different cells that could work for my canister, 4/3AF (1.2v 4500 mah) seemed interesting, but in the end I settled on Sub-C 1.2v 5000 mah cells from Tenergy (Propel).

My goal was to build a pack with about 10 Ah of umph at 12 volt.. So 2 series (10 cells each) in parallel would give me 10 Ah 12 volt. Having large parallel series can however be a problem.. if one cell in a series short circuit internally, then the other series would dump all it's power to it (massive overload). To avoid this I plan to isolate the series using a beefy schottky diode, and also charge them seperately.

I built the pack using 6 rows of 3 batteries (soldered together), and the final two batteries added to the middle. Cut out some plastic lid for top and bottom, and then heat shrink wrapped it all. At the moment I've used some old JST connectors, but I'm waiting to get XT-60 connectors as the JSTs are running a bit too warm for comfort when the light is on.

For charging I bought two pretty cool microcontroller based chargers from Hobby King: Turnigy Accucel-6. They charge pretty much everything you throw at them - and they only cost $23 each!

I've just finished some runtime tests (HID lamp submerged in the kitchen sink), the series have been running for about 1h20m each now. I have not received the diodes yet, so no parallel connection. Anyway, I should have at least 2 hours and 40 minutes of runtime - probably even more (you shouldn't discharge the cells below 0.9v, but there are still around 1.1v left). I'm guessing I should be able to get 3 dives out of this thing when it's fully charged.

Next step is to add XT-60 connectors, diodes, and try it out on a dive :)

We had a tapas night at my place recently with all the usual suspects such as bacon & dates, blue cheese & shrooms, etc.. In addition to this Magnus brought over a large piece of beef tenderloin because he wanted to try out my SousVide-O-Mator. To cook a steak medium-rare the temperature to aim for is 54.5°C, while medium is reached at 60°C. We wanted it closer to medium-rare than medium. The machine was set at 55°C, and left until it would converge on the set temperature. We added the beef (and a bell pepper for some reason.. just to experiment I guess..) and waited. A couple of hours later (you can find the safe temperature vs time (pasteurization time) for your meat over at Douglas Baldwin's site).

The end result is what you see in the picture (not the best picture though, but we wanted to eat it - no time for posing..), we seared it quickly in a pan to kill surface bacteria and to get that nice brown maillard effect. Evenly pink, very moist and very tender.. :)

I've added bluetooth to my controller thanks to a $6 module I found at goodluckbuy.com, this means that I can control it wirelessly and follow temperature graphs from my macbook.



Sous Vide (french for under vacuum) is a cooking technique where food is sealed in airtight plastic bags and submerged in a water bath held at a specific temperature. Cooking sous vide usually takes a long time, but it has the advantage that the food is cooked perfectly evenly, you are able to heat a steak to the exact same temperature through out the entire piece of meat. A cut through a normal steak cooked on a pan usually reveals a gradient going from brown/gray to pink/red in the middle - less heat penetrate to the middle, so when the inside is medium rare the outside is usually well done++. A cut through a sous vide cooked steak looks more like the above - constant color and consistency through out the entire steak (the steak is normally finished (very quickly) in a frying pan to caramelize and kill any surface bacteria). The result tastes really great, and it's hard to mess up - you can leave a steak in the water bath for hours without any problems. Cooking in a bag preserves so much of the moisture in the meat, and the long cooking time breaks down a lot of the connective tissue - leaving you with a perfectly cooked steak that is super-moist and tender enough to eat with only a fork.



Photo by FotoosVanRobin - CC BY-SA 2.0



A professional sous vide setup costs at least >$1000, so it's a bit out of reach for the normal home cook - except for the DIYers.. It's not that hard to build yourself if you put your mind to it. What you need is the following components:

1. Water bath with a electric heater.
2. Some method of circulating the water.
3. A way of accurately regulate the heater based on water temperature
4. Some way of plastic bag packing you meat.

Water bath with heater is easy enough, there are tons of items out there that does this - slow cookers and rice cookers for example. I use a simple rice cooker, the cheaper/simpler the better (we're going to cycle it's power on/off, a dumb cooker will behave better facing a power loss). To circulate the water I use a simple ebay aquarium pump (payed $9.90 for mine). To pack the meat in airtight bags you can either buy a cheap vacuum-packer or simply use zip-lock bags (fill your sink with water, add meat to bag, submerge bag in water but keep the opening above waterlevel - pressure from the water will press out all the air, seal the bag..)

That's the easy part, the hard part is regulating the heater to accurately hit a specific temperature. A simple thermostat won't do, because of the long dead time in such a system - you end up with a cycle overshooting and undershooting the target temperature - this is a job for a real PID controller (proportional–integral–derivative controller).

A PID-controller monitors a system and tries to bring it to a specific state by providing a output value. For example, monitors the temperature of a water bath and tries to bring it to exactly 60 degrees celcius by regulating a heater. The forumula consists of three terms, first the gain - how hard to press the pedel to accelerate to a certain speed based on the current speed. The second part is an integral, looking back, how fast where we changing when we applied this much pressure to the pedal in the past.. Third term is a derivative trying to predict the future, when do I need to stop accelerating to be able to make the next turn.

Implementing such a formula seems straight forward and only requires a few lines of codes - but there are surprisingly many things to concider and special cases to deal with when implementing it - read more about it at Brett Beuregard's blog. Brett has made a nice library for atmel microcontrollers (arduino based), you can find it here: PID v1.

So what I have done is to make a microcontroller based PID controller. It's based on an Atmega 328p chip running the arduino bootloader, it has three buttons and an 4x20 character LCD to handle user interaction. And a DS18B20 one wire temperature sensor to meassure the temperature of my water bath and a SSR (Solid State Relay) to cycle the power of the rice cooker on and off.

It's a fairly simple build, all of the components can be bought cheaply on ebay or electronicsshops like futurlec.

If the video doesn't work, click here:

See schematic and pictures of the setup below:

Bill of materials:

• Atmega 328p (futurlec)
• 3 Buttons (ebay)
• 20x4 LCD (ebay)
• Solid state relay (ebay - Futek) - you might need a heatsink, i use the metal plate in my enclosure.
• Contrast potmeter
• LED
• 16 mhz crystal / ceramic resonnator
• Basic resistors, capacitors, transistors
• Enclosure, preferably with metal backplate (ebay..)
• 220 IEC input and output sockets (futurlec..)
• DS18B20 temperature probe (ebay..)
• Stripboard (ebay)

In total I think it cost me around $30 to build it (not including the pump and rice cooker), not too bad. You could easily make it cheaper by using simpler items - do you really need a 20x4 LCD?

The source code is available at Bitbucket, please feel free to use it for whatever you want: https://bitbucket.org/seikeland/sousvide/overview

Note that the schematic doesn't include power curcuit and programming headers.

I've built the controller into a simple case (w/ metal backplate) I found on ebay. If you have a powerful heater you should concider adding a heatsink to the SSR, they can get hot when switching large currents. With the metal-backplating, my 350W rice cooker never even make the SSR go above room temperature. See pictures of the case and setup below:

Future work:

• It needs a bit of calibration (the gain, integral and derivative) to avoid initial overshoot and small ocillations when changing load.
• Add bluetooth, I have a small bluetooth to ttl module I can connect to get wireless serial (to interface it with pid controller gui)
• Add internal power supply, should be enough space in the box for a 5v transformer.

Stay tuned for more posts on how to calibrate the beast :)

Also, check out eGullet for more information about cooking Sous Vide (temperature tables.. recipes.. safety concerns..)

The MSP430 is a familty of cheap microcontrollers from Texas Instruments featuring ultra low power usage. TI offers a devkit with everything you need to get started (USB-based development board and 2 microcontrollers from the value line) called the MSP430 Launchpad. The killer - it's dead cheap - $4.30 for two microcontrollers and the launchpad including shipping (fedex!). You can also probably manage to get a few MCUs for free as samples. TI is probably selling the kit at a loss really trying to get into the hobbyist market, which is primarily dominated by the Arduino (and to a lesser degree Atmel in general and Microchip Pic). I was very impressed by the power usage, a guy managed to run them for 10 weeks as a clock on a couple of capacitors (granted - 10F caps).

Anyway, I have a 1 hour safety timer connected to my coffee maker (one of those devices that tick down and cut the power after one hour). Being a really cheap device from a low cost "wallmart" like shop I guess it was no surprise when it broke. It doesn't tick down anymore, seems like the motor burned out - it's mostly mechanical with a disc rotating one revolution and then cut the power by physically hitting a switch. I liked having the extra safety this device provided - and wanted a new one. Figured it was a good chance to learn some MSP430 programming. Turning the coffee maker on and off using a relay would be pretty simple, but I really don't want to fuck with 220V mains and leave it without supervision (which probably also voids my home insurance).

I have a few radio controlled Nexa power switches (which are CE certified), so I hooked up one of the MSP430 microcontrollers from the launchpad kit to a remote with a few transistors. Programmed the microcontroller to sleep and wait for a interrupt from small push button, on interrupt it turns on the coffee maker (via the remote - connected with two transistors) and starts a timer. The timer blinks a led every now and then before turning off the coffee maker one hour+ later. Put the whole thing in a small ikea plastic container with 2 AA-batteries, which should last severals years if the MSP430 is as power efficient as they say.

There's a few gotchas when programming the MSP430s, for example the watchdog timer.. The MCU features a watchdog that resets the device after a short time (VERY anoying..), unless you disable the timer - it's on by default. Other than that it was more or less straight forward. You can either use the supplied eclipse-based code composer from texas instruments (proprietary and windows only) - or the open source msp430-gcc toolchain (runs on both linux and mac).. Code written in the code composer will probably not compile using msp430-gcc, there seems to be different syntax for defining interrupts - and intrinsic functions often have different names and functions depending on which compiler you use. I've tried both, the TI software nicely integrates a debugger that can step through lines and instructions in the IDE as they are running on the chip - Spy-Bi-Wire (pretty awesome feature for a $4.30 pricetag). For the open source toolchain you can use mspdebug to open a network port where you can connect using gdb.. providing you with more or less the same features, but it's way more cumbersome to use gdb than a IDE-integrated debugger.. But then again, I don't often use a debugger (even for normal software - my method of debugging often involves throwing prints everywhere), so I guess having to not run the proprietary IDE in a virtual machine is worth the loss of the IDE integrated debugger.

Also, setting up the internal timers required reading quite a lot of TI documentation, more so than other microcontrollers I've tried. The community using it is also small and there are few libraries available. But anyway, got it running - and now it turns on and off my coffee maker.

In conclusion, I don't think TI will make that big of an impact on the hobbyist market with this, the alternatives are easier to use, have better documentation, usefull libraries and less cumbersome development tools. But then again - it's a really cheap way to get started on MCUs.

Posting the coffee timer code as a future reference, maybe some of the boilerplate code can be useful for others as well.
